Ai-3 More
Guida facile e
ingegnosità ovunque.

Scheda Tecnica
Max. power: 7.0 kW @ 3,000 rpm
Max. torque: 25 / 205 Nm @ 0-2,250rpm
Bore x Stroke: 82 mm x 65.6 mm
Max. safe speed: 82 km/h
0~50km/h acceleration: 4.3 sec
Climb capability:30% (17°): 30 km/h
Max. torque: 25 / 205 Nm @ 0-2,250rpm
Bore x Stroke: 82 mm x 65.6 mm
Max. safe speed: 82 km/h
0~50km/h acceleration: 4.3 sec
Climb capability:30% (17°): 30 km/h
Frame: Steel tube
Motor driver: Permanent magnet synchronous motor controller
Cooling system: Air-cooled
Battery connector: Battery port
Transmission: Gearbox transmission with parking brake lock mechanism
Final drive system:Double rear shafts power output with differential gear
Drive mode: Smart / Normal / Sport mode
Throttle control: Electronic
Reverse control: Electronic reverse button
Motor driver: Permanent magnet synchronous motor controller
Cooling system: Air-cooled
Battery connector: Battery port
Transmission: Gearbox transmission with parking brake lock mechanism
Final drive system:Double rear shafts power output with differential gear
Drive mode: Smart / Normal / Sport mode
Throttle control: Electronic
Reverse control: Electronic reverse button
Frame: Steel tube
Front suspension: Telescope
Rear Suspension: Unit swing arm
Front brake: 220mm disc
Rear Brake:180mm disc
Brake system:CBS, Combined brake system
Front Tire:100/90/12
Rear Tire:110/70/12
Front suspension: Telescope
Rear Suspension: Unit swing arm
Front brake: 220mm disc
Rear Brake:180mm disc
Brake system:CBS, Combined brake system
Front Tire:100/90/12
Rear Tire:110/70/12
L x W x H: With rear mirror: 1850 x 730 x 1050 mm
Seat Height: 744 mm
Wheelbase: 1310 mm
Seat Height: 744 mm
Wheelbase: 1310 mm
